RUIBIN—EY20BK
| MODEL | RUIBIN—EY20BK |
| TYPE | Air-cooled, 4-cycle, upright single cylinder, side valve, horizontal PTO shaft |
| Bore x Stroke（mm） | 67x 52 |
| Displacement（CM3） | 183 |
| Continuous output kW(HP)/rpm | 2.3(3.1)/1800 |
| Maximum output kW(HP)/rpm | 3.2(4.3)/2000 |
| Maximum torque N m(kgf m)/rpm | 15/1600 |
| Type of Reduction | 1/2 Gear ?Reduction Type |
| Output shaft Type | Camshaft Putout |
| Direction of rotation | Counter-Clockwise Facing P.T.O.Shaft |
| Fuel | Kerosene(Automobile Gasoline for Starting) |
| Kerosene Fuel Tank capacity(L) | 3.4 |
| Gasoline Fuel Tank capacity liter | 0.17 |
| Lubricant | Engine oil SAE 10W-30,20W,30W |
| Lubrication Oil Capacity (US gal.) | 0.6(0.156) |
| Lubrication | Mechanical splashing type |
| Carburetor | Float type |
| Starter | Recoil starter |
| lgnition system | Transistorized |
| Dry weight Kg | 16 |
| Packing Size(cm) | 38×38×45 |
